TE Connectivity - Ring Tongue Terminal AWG 16-14 Insulation Max 2.92mm Stud M4 | 320565

TE Connectivity - Ring Tongue Terminal AWG 16-14 Insulation Max 2.92mm Stud M4 | 320565

The Tyco AMP 320565 Terminal is a closed barrel, ring tongue terminal for wires AWG 16-14. It has a Pre-Insulated Diamond Grip (PIDG) body made from copper with a tin finish, and blue nylon insulation.

Product Type Features:

• Terminal Shape: Ring Tongue
• Receptacle Style: Straight
• Body Style: PIDG
• Barrel Type: Closed Barrel
• Wire/Cable Type: Regular Wire
• Insulation: Yes
• Insulation Support: Insulation Support
• Insulation Diameter (mm [in]): 2.92-4.32 [.115-.170]
• Stud Diameter (mm [in]): 4.34 [0.171]
• Stud Size: 8 [M4]
• Shape: RING-041
• Heavy Duty: No
• Material: Copper
• Finish: Tin
• Color: Blue
• Insulation Material: Nylon

Electrical Characteristics:

• Voltage (VAC): 300

Termination Features:

• Wire/Cable Size (CMA): 2,050 – 5,180

Body Features:

• Wire Range (mm [AWG]): 1.25-2.00² [16-14]
• Tongue Material Thickness (mm [in]): 0.79 [0.031]

Industry Standards:

• Government/Industry Qualification: No
• RoHS/ELV Compliance: RoHS compliant, ELV compliant
• Lead Free Solder Processes: Not relevant for lead free process
• RoHS/ELV Compliance History: Always was RoHS compliant
• Conditions for Usage:
• Temperature Range (°C): 105
• Packaging Features:
• Packaging Method: Loose Piece

Other:

• Brand: AMP
• Comment: Available On-Tape for Automatic Termination.
