AeroLEDs - Pulsar NS Series Navigation Lights

CERTIFIED AeroLEDs - Pulsar NS Series Navigation Lights

Built for Safety, built to last. These certified LED navigation lights are designed for some of the most extreme operating conditions. Pulsar LED wingtip lights are built using a single solid-state circuit board, polycarbonate lens, internal reflectors, anodized aluminum heatsink, and a hard outer coat for UV protection and scratch prevention.

The Pulsar NS Series Navigation Lights have LED Navigation and Strobe Lights designed for airplane wingtips and wingtip cut-outs. They exceed TSO effective candela requirements. This light is the same size as the traditional forward and rear-facing Position and Anti-Collision Lights for simple drop-in replacement. The Pulsar also does not require an external power supply! Pulsar Navigation Lights fit the mounting footprint of legacy incandescent lighting. The NS Series is TSO Certified! These lights meet C-30c, Type I, II, III, and C-96a, Class II.

Specifications:

• Part Number: 12V (11-1280-B-12) 24V (11-1280-B-24)
• Power: 22 Watts (Per Pair)
• Voltage: 12V (9-18 VDC), 24V (18-36 VDC)
• Candela: Exceeds TSO candela requirements
• Weight: 6.6 oz
• Dimensions: 4″ x 1.9″ x 1.5″
• Class: FAA, TSO C-30c Type I, II, and TSO C96a Class II
• Pulsar NS Series Navigation Lights Installation Instructions
